SBR Based Sewage Treatment Plant
SBR Based Sewage Treatment Plant
SBR Based Sewage Treatment Plant

SBR Based Sewage Treatment Plant

Sewage Water Treatment Plant (STP)

Engineered using advanced Sequential Batch Reactor (SBR) technology, our Sewage Treatment Plants offer a compact, cost-effective solution for treating domestic and municipal wastewater. The SBR process combines equalization, aeration, and clarification within a single tank, operating in timed batch cycles � fill, react, settle, decant, and idle � eliminating the need for separate clarifiers and reducing overall footprint. This makes it ideal for residential complexes, hotels, hospitals, schools, and industrial townships with space constraints. The system delivers consistently high-quality treated water suitable for gardening, flushing, or safe discharge, while meeting CPCB and state pollution control norms. With fully automated PLC-based operation, minimal manual intervention, low sludge generation, and energy-efficient aeration, our SBR plants ensure reliable, low-maintenance performance and long-term operational savings for our clients.

₹500,000

  • Specification
  • Applications
Product Name SBR Based Sewage Treatment Plant
Capacity Customizable (1 KLD – 500+ KLD)
Material MS / FRP / RCC
Technology Sequential Batch Reactor
Operation Fully Automatic (PLC based)
Maintenance Low
Power Requirement 3 Phase
Warranty 12 Months
Residential apartments & gated communities
Hotels & resorts
Hospitals & healthcare facilities
Educational institutions
Industrial townships & commercial complexes
Municipal sewage treatment projects
